CÓDIGO: MAB760PRS4W
| Marca | Asrock |
| Part Number | 90-MXBMY0-A0UAYZ |
| CPU | - Supports 14th, 13th & 12th Gen Intel® Core™ Processors (LGA1700) |
| Chipset | B760 |
| Memoria | - Tecnología de memoria Dual Channel DDR4 - 4 x ranuras DDR4 DIMM - Soporta memoria DDR4 non-ECC, un-buffered up to 5333+(OC)* - Soporta módulos de memoria ECC UDIMM (operan en modo no-ECC) - Máxima capacidad de memoria del sistema: 128GB* - Soporta Intel® Extreme Memory Profile (XMP) 2.0 |
| BIOS | - 128Mb AMI UEFI Legal BIOS with GUI support |
| Gráficos | - Intel® Xe Graphics Architecture (Gen 12) - 1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and max. resolution up to 4K 60Hz - 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz |
| Audio | - 7.1 CH HD Audio (Realtek ALC897 Audio Codec) |
| LAN | - 2.5 Gigabit LAN 10/100/1000/2500 Mb/s |
| Ranuras de Expansión | 1 x PCIe 5.0 x16, 1 x PCIe 4.0 x16 (modo x4), 2 x PCIe 3.0 x1 |
| Conectores | Conectores internos: Alimentación ATX 24-pin, 8-pin 12V, 4-pin 12V; 1x USB 3.2 Gen1 Header, 2x USB 2.0 Headers; 1x Front Panel Type C USB 3.2 Gen2x2 Header |
| Panel trasero E/S | 2x Antenas, 1x PS/2, 1x HDMI, 1x DisplayPort, 1x USB 3.2 Gen2 Type-A, 1x USB 3.2 Gen1 Type-C, 2x USB 3.2 Gen1 Type-A, 2x USB 2.0, 1x RJ-45, 3x Audio Jacks |
| Caract. Especiales | ASRock Polychrome RGB, Nahimic Audio, ASRock Auto Driver Installer, Blazing OC Tuner, EZ Set |
| CD de Soporte | Drivers, Utilidades, Software Antivirus |
| Accesorios | 2 x Cables de datos SATA, 1 x Antena WiFi 2.4/5/6 GHz, 1 x Tornillo para Socket M.2 |
| Formato | ATX |
| Certificaciones | FCC, CE |
| Socket | LGA1700 |
| Almacenamiento | CPU: - 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode* Chipset: - 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode* - 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode* - 4 x SATA3 6.0 Gb/s Connectors |
| RAID | Si |
| Wifi | - 802.11ax Wi-Fi 6E Module |
| USB | Total: 10 puertos USB (2x USB 3.2 Gen2, 5x USB 3.2 Gen1, 3x USB 2.0), incluyendo Type-A y Type-C |
| Red Inalámbrica | Wi-Fi 6E (802.11ax) + Bluetooth 5.3 |
